CTS high power 30kwh 96v lithtium battery pack 96v 200ah 300ah lifepo4 battery for ev boats
CTS offers a 96V high - power lifepo4 battery for EV boats. With a capacity of 200ah and 300ah, providing 30kwh of power, this battery is engineered to meet the power requirements of EV boats, ensuring reliable performance and long - lasting energy supply. With advanced technology and strict quality control, it enhances the efficiency and operation of EV boats.
Description
CTS high power 30kw 96v 300ah lithtium battery pack for ev boats
Why Choose CTS E-Boat Lithium Battery?
- Marine Durability: 304/316 stainless steel housing suit for marine use and able to withstand vibrations, shocks, and corrosive elements.
- Maximum Safety: Lifepo4 battery comes with an intelligent BMS for top-notch safety.
- Space-Efficient Design: Designed to save space on your boat without sacrificing performance.
- Long Life Cycle:CTS LiFePo4 batteries last over 4,000 cycles at 80% DOD, outlasting lead-acid batteries for longer motor power.
- Easy Integration: Seamlessly fits into your marine systems, and compatibility with different electric boat setups.
- Customizable Battery Pack: customize the most suitable size for your boat
- Reliable Support: 24/7/365 on-line service provide instant technical support from design to delivery.
PRODUCT INTRODUCTION
OEM/ODM
100% After-Sales Gurantee 100% Free Technical Support Fast Delivery
◆ Longer cycle life, more Powerful
◆ Built-in smart BMS monitor battery state
◆ Extremely safe, no explosion, no fire under collision
◆ Cooling and heating system optional
◆ Customized battery solutions base on yours requirements
◆ Excellent large current discharge performance
◆ Low self-discharge and good discharge performance at low temperatures
◆ Built-in smart BMS monitor battery state
◆ Extremely safe, no explosion, no fire under collision
◆ Cooling and heating system optional
◆ Customized battery solutions base on yours requirements
◆ Excellent large current discharge performance
◆ Low self-discharge and good discharge performance at low temperatures
The Paramerters of 96V 300AH LiFePO4 Battery Pack
|
MODEL
|
CTS-96300
|
|
Cell Type - Chemistry
|
Prismatic- LiFePO4
|
|
Rated Capacity
|
304Ah
|
|
Rated Voltage
|
96V
|
|
Energy
|
29.18KWh
|
|
Resistance
|
30mΩ
|
|
Self Discharge
|
<3% per month
|
|
PDU
|
BMS, 400A relays, fuses, COM socket
|
|
Dimensions (L x W x H)
|
L1300*W500*H380mm
(Can make it smaller if you want)
|
|
Weight
|
250Kg
|
|
Enclosure Protection
|
IP67 stainless steel case
|
|
Discharge Cut-off Voltage
|
75V
|
|
Max Continuous Discharging Current
|
300A
|
|
Peak Discharge Current
|
400A for 60 seconds
|
|
Recommended Discharge Current
|
300A
|
|
Charging Limited Voltage
|
109.5V
|
|
Max Charging Current
|
200A
|
|
Recommended Charge Current
|
100A
|
|
Charge Temperature Range
|
0~50℃
|
|
Discharge Temperature Range
|
-20~60℃
|
|
Recommended Operating Temperature
|
15~35℃
|
|
Available on request
|
Size, C rate, Communication protocol
|
The Advantages of 96V 300AH LiFePO4 Battery Pack
- Most safe LFP battery technology
LiFePO4 battery is an excellent option for electric boats due to its high energy density, long cycle life, low self-discharge rate, high discharge rate, fast charging, and safety. It provides a reliable, efficient, and eco-friendly power source for electric boats, allowing them to travel longer distances and operate more smoothly.
- Laser Welding
It can further strengthen the connection and completely eliminate the risk of screws falling. The contact surface between the screw and the bus bar is reduced to improve the current capability. lt can also reduce
internal resistance and reduce power consumption.
internal resistance and reduce power consumption.
- Smart BMS to manage the battery
Short-circuit protection,Overcharge and over-discharge protection, and over-temperature protection to ensure the safety of the battery..
Cell balancing, Temperature sensing and control, State-of-charge (SOC) estimation, Real-time monitoring and management,
Communication interface:CAN,RS485 optional .
- Stainless steel case with IP67 waterproof
304/316 stainless steel case is highly resistant to corrosion, making it suitable for use in variousenvironments, including marine and chemical industries.
A stainless steel case with IP67 waterproof rating offers a rugged, long-lasting, and moisture-resistant enclosure that provides protection for battery pack in harsh environments.
- Optional thermal management system
liquid cooling and heating system can adapt the battery to different working environment
temperatures .Battery thermal management systems are designed to regulate the temperature of batteries in electric vehicles or other battery-powered systems. It is good in maintaining the overall health and performance of batteries. that helps maintain the optimal temperature to ensure optimal battery performance.
temperatures .Battery thermal management systems are designed to regulate the temperature of batteries in electric vehicles or other battery-powered systems. It is good in maintaining the overall health and performance of batteries. that helps maintain the optimal temperature to ensure optimal battery performance.
Product Applications
The dvantages of 96V 300AH LiFePO4 Battery Pack
CTS lithium battery has a wider range of application and can meet 90% of yacht , tour boat, and speedboat products in the market，According to the size requirements of the ship, we can design and customize the matched
lithium battery system. CTS provides one-stop battery service. we also can provide PDC，OBC, charge piles etc..
lithium battery system. CTS provides one-stop battery service. we also can provide PDC，OBC, charge piles etc..
